The anti-drop collision radar sensor is a critical safety upgrade for any barrier gate system, whether using lighter plastic-cased arms or heavy-duty steel booms. This sensor’s advanced algorithms are programmed to recognize the presence of a vehicle beneath the gate and maintain an 'open' status until the path is entirely clear. By preventing the boom arm from dropping prematurely, the sensor eliminates the risk of expensive gate damage and associated liability. The system’s high-frequency radar technology is resistant to the effects of extreme temperatures, making it a reliable solution for year-round operation in various climates. With a straightforward universal mounting system, it integrates quickly with almost any barrier gate controller, offering immediate safety benefits with minimal setup time.
In short, the Anti-Drop Collision Radar Sensor for Plastic and Steel Barrier Gates Protection is a factory-direct radar vehicle detector...
| Material | Plastic | Reflective Grade | Engineer Grade |
| Brand Name | Baroxon | Model Number | Ba-79G-PRO |
| Product Name | Radar Vehicle Detector | Refresh Rate | 13.3Hz |
| Response Time | 75ms | Product Weight | 183g |
| Operating Frequency | 77GHz-81GHz | Detection Distance Range | 0.5m~0.7m |
| Detection Level Range | -1~1m | Debugging Mode | Bluetooth / Serial |
| Packing Size | 112.75mm*111.75mm*47.81mm | Horizontal Beam | 120° |
Tutorial Video: Installing Baroxon Radar Sensor for Mexico Automatic Barrier Systems
| Parameter Details - Baroxon Ba-79G-PRO | |
|---|---|
| Frequency Range | 77GHz - 81GHz (High Precision) |
| Horizontal Detection Angle | 120° Wide Coverage |
| Vertical Detection Angle | ±15° Adjustable |
| Communication Interface | Bluetooth, Serial Port, Relay Node |
| Operating Temperature | -40°C to +85°C (Suitable for Mexico tropical climate) |
| Waterproof Rating | IP67 High Level Protection |
Q1: Is Baroxon radar easier to install than traditional ground loops in Ciudad de Mexico projects?
Absolutely. Traditional ground loops require road cutting which is time-consuming and prone to damage from heavy rain. Baroxon radar can be mounted directly on the barrier gate housing, saving installation time and maintenance costs for projects in Ciudad de Mexico, Guadalajara, or Medan.
Q2: Can the detection distance be adjusted for narrow toll booths or parking exits?
Yes, the Ba-79G-PRO features an adjustable detection distance (0.5m-0.7m standard, configurable via Bluetooth) to prevent false triggering from adjacent lanes or pedestrians, making it ideal for mall parking and residential barrier gates.
Q3: Does the radar support all types of Mexico barrier arms?
Yes, it works perfectly with 90° Folding Arms, Fence Arms, and straight Boom Gate poles. It provides high-reliability anti-drop protection for vehicles ranging from motorcycles to large trucks.
| Selling Units | Single item per box | Package Dimensions | 12 x 12 x 5 cm |
| Gross Weight | 0.183 kg | Batch Availability | Stock available for Ciudad de Mexico delivery |
Automatic Parking Barrier | Sales Radar Barrier Gate | Sensor Radar Parking Affordable | Vehicle Loop Detector Mexico | Anti Tabrak Barrier Gate | Access Control Parking | 79GHz Millimeter Wave Radar Ciudad de Mexico
Distributor Parking Barrier Mexico, Radar Sensor Barrier Automatic, Smart Parking System Hardware, Service Pasang Barrier Gate Guadalajara, Sensor Parking RFID, Components Parking Barrier, Automatic Boom Gate Sensor, Radar Anti-Drop Vehicle, Parking System Berbayar Mandiri, Radar Sensor For Barrier Gate MX-50, Spare Parts Parking Barrier Bandung, Teknologi Parking Pintar, Parking Lot Safety Sensor, Millimeter Wave Radar for Toll Gate Mexico.
The operator supports adjustable travel profiles from 0.6s / 0.9s for high-traffic lanes up to 1.5s–6s for long or heavy arms, configurable on site.
Straight, folding (90°/180° articulated) and fence arms from 1 m to 6 m, selected according to lane width, wind load and clearance.
Yes. Power input accepts AC 110–240V 50/60Hz plus DC 24V brushless variants, so it matches Mexican electrical standards (127V/60Hz).
Yes. The control board supports ANPR/LPR camera terminals, RFID/UHF long-range readers, loop detectors, QR codes and third-party parking management software through dry contacts, Wiegand or network interfaces.
Units include manual clutch release and automatic arm-lift failsafe. Optional battery or UPS backup keeps the gate operating in unattended car parks.
Rated for 3–10 million MCBF cycles with MTTR under 30 minutes thanks to the modular design. Standard 1-year warranty, lifetime technical support, ISO 9001 / ISO 14001 / ISO 45001 and CE certified.
The MOQ is 1 unit for sample orders, with volume discounts from 10 units. Mixed container orders combining barriers, turnstiles and sensors are welcome.
Factory-direct prices for this category range from USD 100 to USD 5,000 depending on model, arm length, motor type and access control configuration. Send your site details on WhatsApp for a quotation within 24 hours.
Stock units ship in 3–7 days; customized production takes 15–25 days. Sea freight to Mexican ports (Manzanillo, Lázaro Cárdenas, Veracruz) usually takes 25–35 days; air freight is available for urgent projects.
